Twin Action System: The mechanical action consists of the movement of the central brush

(1) which collects the material from the ground and conveys it to a hopper where it is shredded by a rotating shaft equipped with hammers

(2). At this point, by means of the vacuum action

(3), the material is raised to the collection hopper

(4), while the sucked air is filtered

(5) and returned to the environment perfectly clean

Reduction of fuel consumption and atmospheric emissions thanks to the high-performance hydraulic system and the EURO VI engine, specific for industrial applications, certified in accordance with the strictest atmospheric emissions standards in its category.

Greater operator comfort and reduction of stress even during the longest work shifts thanks to the position of the engine, located at the rear of the vehicle, the soundproof cab, and the use of hydraulic suspensions.

The cleaning action is concentrated only on the central brush: the side brushes are used only to convey the dirt from the edges (pavements or walls) to the operating area of the central brush, which collects both debris and dust thanks to the highly efficient vacuum action.

Technical Details :

Working width with central brush (mm) 1400

Working width with two side brushes (mm) 2480

Working width with two side brushes and swinging brush (mm) 3230

Central brush (Ø/mm) Ø580×1400

Side brush (mm) 900

Standard filter (format) Pocket

Standard filter (material) Polyester

Filtering surface (sq.m.) 50

Capacity of waste container (l) 6000

Type of drainage: Hydraulic

Supply/traction (V) Diesel 143HP-105KW/Hydraulic
